Quantela platform user manual

English: en

Italian - it

Hindi - hi

Dutch - de

Arabic - ar

Russian - ru

Japanese - jp

Slovensky - sk

console - function scripts can use console.log, console.info and console.warn. For example: console.log("Input Object", {a: 1, b: 2})

R - custom functions can take advantage of the whole RamdaJS functional library. For example:

Rename keys

Renames the keys to a user-friendly format.

const renameKeys = R.curry((keysMap, obj) =>
    R.reduce((acc, key) => R.assoc(keysMap[key] || key, obj[key], acc), {}, R.keys(obj))
);
R.map(renameKeys({
    "": 'Status',
    'Ward/Mandal': 'Ward',
    'Hospital District': `hospital`,
    'Zone/District': `Zone`
}), input);

Group by property and add results on the specified property

Groups by a property and then adds the results based on the specified property.

const sumBy = prop => vals => reduce(
    (current, val) => evolve({
        [prop]: add(val[prop])
    }, current),
    head(vals),
    tail(vals)
)
const groupSumBy = curry((groupOn, sumOn, vals) =>
    values(map(sumBy(sumOn))(groupBy(prop(groupOn), vals)))
)

Merge multiple arrays into one array

Merges multiple arrays into one single array.

fn = R.pipe(
        R.map(R.indexBy(R.prop('property'))),
        R.reduce(R.mergeWith(R.merge), {}),
        R.values
    ),
    newArray = fn([arrayOne, arrayTwo, arrayThree])

Merge arrays based on the index property

Merges arrays based on the specified property.

R.map(x => {
            data = R.values(R.mergeWith(
                R.mergeLeft,
                R.indexBy(R.prop('property'), input),
                R.indexBy(R.prop('property'), x)
            ));
        }

Filter by a property and find the length of the result using 'compose' function

Filters based on a property and then finds the length based on the result using the compose function.

R.compose(R.length, R.filter(R.pathEq(['property'], 'value')))(input);

Group by any property

Groups by the specified property.

R.groupBy(R.prop(property));

Sums data based on properties

Adds the data based on the specified property.

R.sum(R.map(item=> item.property,data));

Reject or omit few records

Rejects or omits the records which satisfies the condition.

R.reject(x => x.property == 'value', data);

Data modification using the 'map' function

Data transformations using the 'map' function.

let output = R.map((device) => {
    For ex: // Converting Unix time to ISO string.
    device.last_updated = new Date(device.payload.d.t * 1000).toISOString();
    return device
}, deviceDetails)

Unique by property

Filters the unique values based on the specified property.

R.uniqBy(R.prop("property"), input);

Multilevel Group by

Groups by using multiple 'group bys'.

const groupByLetterNumberBool = pipe(
    groupBy(prop("letter")),
    map(groupBy(prop("number"))),
    map(map(groupBy(prop("bool"))))
);

Pluck by given property

Plucks the data by the specified property.

R.sum(R.pluck('property')(data));

Key-Value Pair Converter

Converts two separate keys to a single key-value pair.

{
    "name": "",
    "value": ""
} == > {
    name: value
}
R.pipe(R.indexBy(R.prop('name')), R.map(R.prop('value')))(input);

Papa Parse - the papaparse JavaScript parser can be used to parse CSV strings.

moment - the moment.js library can be used to parse, validate, manipulate, and display dates and times. For example:

Time conversion to specific time zones

Converts the timestamp from UTC to the specified time zone.

moment.utc(timestamp).tz('America/New_York').format('YYYY-MM-DD HH:mm:ss z');

JSONata - jsonata expressions can be used to query and transform data. For example:

Group by property and sorting

Groups by the specified property and then sorts it.

$${$string(`property`):{"Zone":count}}
$${$string(`property`): $.{ "status": status, "timestamp": timestamp }^(> timestamp)}

JSONata Filter function

Filters the property.

$filter($$, function($v, $i, $a){($v.property!=null)}

Filter based on count and variables

Filters the data based on the count and the specified variables.

($my: = $$ {
    `Patient Name`: {
        "a": `Patient Name`
    }
}; $patientName: = $my.*[$count(a) > 1].a[0]; $$[`Patient Name` in $patientName])

JSONata expression execution

Dynamic execution of an expression.

let expr = jsonata("$$.*");
expr.evaluate(data)
or
jsonata("$$.*").evaluate(data);

Group and sum of a column

Groups and adds the results based on the specified property.

$$ {
    key: $sum(property)
}~ > $each(function($v, $k) {
    {
        "key": $k,
        "key": $v
    }
})

Merge all objects in an array

Merges all the objects in an array.

$zip( * .$keys(), *.*) {
    $[0]: $[1]
}

UTILS.datasets - we can use UTILS to invoke datasets using the syntax UTILS.datasets(datasetName, payload). For example, if there is a dataset called 'Get Light by Id' and it takes vendor_name and light_id as inputs then we can invoke this as follows:

let light = await UTILS.datasets("Get Light by Id", {vendor_name: "Bajaj", light_id: 12345})

Error Handling if adapter/dataset returns an error or an empty response

let data = await UTILS.datasets("data-set-name", {
    "key": value
})

if (data.error) {
    outputs.content = []
} else {
    outputs.content = data;
}

UTILS.connectors - we can invoke connectors using the syntax UTILS.connectors(connectorName, input). For example:

let my_connector = await UTILS.connectors(
    "Connector Name",
    {"payload": "your input payload"}
)

UTILS.functions - we can also invoke any built-in functions within our scripts using the syntax UTILS.functions(functionName, input, args). For example:

let light = await UTILS.functions(
"JSON To CSV",
[ {a: 1, b: 2},{a: 3, b: 4},{a: 5, b: 6},{a: 7, b: 8} ],
[",", "\r\n"]
)

Note that all functions, connectors and datasets methods are asynchronous, so you will need to either catch Promises or use await while invoking.

UTILS.redis - we can store or retrieve data from Redis using the following:

UTILS.currentUser - we can get the logged in user's info and roles using the syntax let data= await UTILS.currentUser().

UTILS.flowContext - we can get the current flow context using the syntax let data= UTILS.flowContext.

mock - functions can use Mock.js to generate simulation data.

turf - function scripts can use Turf.js for geospatial analysis.

through2 - through2 can be used as a pipe for modifying or transforming streams.

X2JS - the X2JS library is a convenient tool for converting between XML and JSON objects.

logger - used to log messages from the custom functions.

cheerio - cheerio can be used to parse HTML. For example:

const $ = cheerio.load('<h2 class="title">Hello world</h2>')
$('h2.title').text('Hello there!')
$('h2').addClass('welcome')
$.html()

crypto - crypto is an encryption utility for crypto standards. The syntax is crypto.HmacSHA1("Message", "Key").

google - Google's official node API feature. Google Spreadsheets is one of the subset API. You can refer to it here. For example, to ask for permissions from a user to retrieve an access token, you redirect them to a consent page. To create a consent page URL:

const oauth2Client = new google.auth.OAuth2(
  YOUR_CLIENT_ID,
  YOUR_CLIENT_SECRET,
  YOUR_REDIRECT_URL
);

// generate a url that asks permissions for Blogger and Google Calendar scopes
const scopes = [
  'https://www.googleapis.com/auth/blogger',
  'https://www.googleapis.com/auth/calendar'
];

const url = oauth2Client.generateAuthUrl({
  // 'online' (default) or 'offline' (gets refresh_token)
  access_type: 'offline',

  // If you only need one scope you can pass it as a string
  scope: scopes
});

FeedParser - FeedParser is used to parse RSS feeds and can be initialized using the following syntax:

//initialise FeedParser
var feedparser = new FeedParser([options]);

Select the JSON option to view it as a structured sequence of attribute-value pairs. You can click on any field in the structure to expand it and see the lower level data, and click again to collapse it. Alternatively click the Expand All Fields and Collapse All Fields buttons which apply to the whole JSON structure.

Select the Text option to view the data as unstructured data.

Select the Map option to view the data on a geographical map. This option is only applicable to GeoJSON data. Each location would be displayed on a world map so that you can verify that the format and content of the data returned by the provider is correct.

In the Input option, the data which was entered in the Default Data field of Node Inputs in the Configuration would be pre-populated here without needing to enter the data again.
